# Wheel Hub Bearing Kit Contents: What Distributors Should Specify

A wheel hub bearing kit is a commercial service package built around a wheel-end bearing or hub assembly. Depending on the application, it may include only the bearing, or it may also contain a hub flange, axle nut, circlip, seals, mounting bolts, dust cap, gasket, ABS sensor, connector hardware, or installation accessories. The word “kit” does not define a universal bill of materials.

For distributors, private-label buyers, and catalog teams, the safest rule is: treat kit contents as controlled product data, not as a marketing description or an illustrative photograph. Every included component should have a name, quantity, specification or drawing reference, material or finish where relevant, and packaging position. That controlled bill of materials should remain consistent across the quotation, purchase order, sample approval, artwork, warehouse record, and customer catalog.

What Is Normally Included in a Wheel Bearing Kit?

The answer depends on bearing generation and vehicle service procedure. SKF’s hub-bearing technical material notes that wheel bearing and assembly kits can contain a bearing and additional hardware such as wheel flanges, retaining rings, gaskets, and mounting nuts. A press-in Gen 1 application may need a circlip and new axle nut. A bolt-on Gen 3 assembly may already integrate the flanges and ABS target but require new mounting bolts. Another application may need only the hub unit because service hardware is reused under the vehicle manufacturer’s instructions.

Component group	Possible kit item	Main control point
Core wheel-end component	Bearing, flanged bearing, hub assembly	Exact application, generation, dimensions, ABS configuration
Retention	Axle nut, locknut, circlip, snap ring, retaining plate	Thread, size, direction, coating, one-time-use rule
Sealing	Oil seal, dust seal, O-ring, gasket, cap	Material, lip orientation, mating diameter, installation side
Mounting hardware	Bolts, studs, washers, nuts	Grade, coating, thread, length, captive or loose supply
ABS hardware	Encoder, tone ring, sensor, cable, connector, clips	Signal type, orientation, cable length, connector keying
Installation aids	Protective sleeve, transport cap, spacer	Removal timing and installation purpose
Information	Label, application note, warning, traceability code	Language, revision, lot linkage, regulatory requirements

Not every kit should contain every item. Extra hardware can be as problematic as missing hardware if it causes the installer to use an incorrect fastener or discard a reusable original component.

Start With the Service Architecture

Before defining kit contents, classify the wheel-end design. A Gen 1, Gen 2, or Gen 3 hub bearing has different mounting and service interfaces.

Gen 1 press-in bearing kits

A typical press-in bearing kit may include:

Double-row wheel bearing
One or more retaining circlips
Axle or hub nut
Separate seals where the application requires them
A hub flange only when the commercial kit is deliberately sold with one
Protective packaging to prevent seal or magnetic encoder damage

The bearing must still be controlled by bore, outside diameter, width, rolling-element design, sealing, internal geometry, and encoder orientation. The kit BOM does not replace the part drawing.

Gen 2 flanged bearing kits

A Gen 2 design contains one integral flange. The kit may add:

Retaining hardware for the non-flanged interface
Wheel studs or mounting bolts if not already assembled
Axle nut for a driven application
ABS-related protective parts
Seal, gasket, or dust cap where required

The buyer must identify whether the flange belongs to the rotating or stationary ring and which mating component it supports.

Gen 3 hub assembly kits

A Gen 3 unit is more integrated and commonly includes wheel-side and suspension-side mounting functions. The assembly may already contain studs, a magnetic encoder, or an integrated sensor. A commercial kit can also include:

Suspension mounting bolts
Axle nut
O-ring or mounting gasket
Dust cap
Sensor cable clips or brackets
Application-specific warning or installation note

Do not assume that a complete-looking hub assembly includes every fastener required by the vehicle service procedure.

The Core Bearing or Hub Assembly

The central component should have its own controlled identity independent of the kit number. Record the manufacturer part number, customer part number, drawing revision, OE references, application status, and inspection plan. If the core component changes, the kit must enter change control even when the outer carton and commercial SKU stay the same.

Important core-component fields include:

Bearing generation and construction
Ball or tapered-roller arrangement where applicable
Driven or non-driven configuration
Flange count and mounting architecture
Spline data
Wheel and brake pilot diameters
Bolt pattern and mounting threads
ABS encoder or tone-ring configuration
Integrated sensor and connector details
Seal system and handling requirements

For terminology differences, see wheel hub bearing versus wheel hub assembly.

Axle Nuts and Locking Hardware

An axle nut is frequently included because many service procedures specify replacement after removal. However, the kit owner must verify that the supplied nut matches the application and service method.

Control at least:

Thread diameter and pitch
Thread direction if application-specific
Nut style and bearing surface
Height and across-flats dimension
Flange, washer, cage, cotter-pin, staking, or prevailing-torque feature
Material and mechanical property requirement
Plating or corrosion-protection system
Lubricated or dry torque condition where defined by the service source
Single-use identification and installation note

The kit label should not invent a torque value. Torque can depend on the vehicle manufacturer, nut design, lubrication state, and service procedure. If torque guidance is included, it must be traceable to an approved source and tied to the exact application.

Circlips, Snap Rings, and Retaining Plates

Retaining rings appear simple but can differ in thickness, free diameter, lug geometry, material, heat treatment, and coating. An undersized or incorrectly oriented ring may not fully engage the groove. A ring that is too thick may prevent assembly.

The BOM should specify:

Ring type and standard or drawing
Nominal diameter and thickness
Material and hardness
Surface finish or coating
Quantity
Installation side or orientation if relevant
Packaging method that prevents deformation or loss

If two similar rings are included, separate them visually and in the instructions. Do not place loose rings against the bearing seal or magnetic encoder.

Seals, O-Rings, Gaskets, and Dust Caps

Some applications use separate sealing components around the bearing or hub. These parts must match the mating diameter, groove, housing, lubricant, temperature, and environmental exposure.

A seal line item should state:

Seal type and cross-section
Material family when controlled
Shaft and housing dimensions
Lip direction or installation side
Grease or oil compatibility
Protective treatment and storage requirement
Whether the part is installed on the hub or supplied loose

Dust caps and transport caps are not interchangeable. A service dust cap remains on the vehicle; a shipping protector is removed before installation. Packaging and instructions should make that difference unmistakable.

Mounting Bolts, Studs, Nuts, and Washers

Mounting hardware requires more than a count. A bolt with the correct thread but wrong grade, under-head geometry, coating, or length can create a clamping or clearance problem.

Record:

Thread diameter, pitch, and tolerance class
Effective thread and overall length
Head style and drive
Strength grade or property class
Washer type or captive washer
Coating and corrosion requirement
Thread-locking patch where specified
Quantity per kit
Whether hardware arrives assembled or loose

Wheel studs installed in the flange need their own drawing controls for thread, knurl, under-head geometry, projection, material, heat treatment, and press-fit condition. A visual check alone cannot approve a stud.

ABS Sensors, Encoders, and Cable Accessories

An integrated hub may include a wheel-speed sensor, while another unit uses only a magnetic encoder read by a vehicle-mounted sensor. Kit contents must distinguish the signal target from the sensor itself.

For an included sensor, control:

Sensor technology and application
Connector housing, keying, and pin count
Cable length and branch geometry
Grommets, clips, and mounting brackets
Connector cap and electrostatic or moisture protection
Resistance or electrical test method where applicable
Routing instruction and strain-relief points

For a magnetic encoder, protect the active face from impact, metal particles, and strong external magnetic sources. The ABS magnetic encoder handling guide explains orientation and inspection risks.

Protective Sleeves and Installation Aids

Some seals or bearing interfaces use a temporary sleeve to protect a lip during installation. Other packages use plastic caps or spacers only to keep contaminants away during transport. If such parts are included, state their purpose and removal point.

An installation aid should never look like an optional loose accessory. Use a contrasting bag, a labeled compartment, or a clear instruction. If premature removal can damage a seal or encoder, include that warning in the packaging specification and sample review.

Build a Controlled Kit Bill of Materials

A useful kit BOM contains one row for every item rather than a sentence such as “bearing with accessories.”

BOM field	Purpose
Line number	Stable reference during review and corrective action
Component number	Identifies the exact controlled item
Description	Uses unambiguous technical terminology
Quantity	Prevents incomplete packs and overpacking
Drawing or standard revision	Links the supplied part to approved requirements
Material/grade/coating	Controls functional hardware attributes
Installed or loose	Defines assembly state
Pack position	Supports poka-yoke and visual inspection
Inspection requirement	Identifies dimensions or features checked at pack-out
Change status	Shows whether the component is approved, provisional, or superseded

The customer-facing catalog may show a simplified contents list, but it should be generated from the controlled BOM rather than maintained independently.

Sample Approval: Verify the Kit as a System

Sample approval should compare the physical kit against the BOM and application requirements.

Confirm the core bearing or hub part number and drawing revision.
Count every loose component and verify its identification.
Measure critical fastener, ring, seal, and cap attributes.
Check that hardware does not damage the bearing during transport.
Verify the featured image and catalog contents against the physical sample.
Review label, barcode, lot code, application, quantity, and country-of-origin fields as applicable.
Perform fitment validation under the approved vehicle or fixture process.
Record deviations and approve the final golden sample or limit sample.

If the kit includes multiple bags, each bag should have its own identity or visual control. Counting only the outer carton is not sufficient.

Packaging the Kit for Export

Export packaging must control corrosion, shock, vibration, loose-part movement, and label integrity. A heavy hub assembly can crush a small accessory bag if both move freely inside the carton. Metal hardware can also strike the encoder or seal.

Practical controls include:

Separate cavities or bags for loose fasteners and rings
Rigid protection over studs, connectors, and encoder faces
Corrosion-prevention method appropriate to route and storage duration
Inner support that prevents the hub from contacting carton walls
Scannable product and lot labels after normal handling
Defined carton drop, vibration, compression, or transport validation where required
Pack-out checklist linked to the kit BOM

Private-label artwork should be revision-controlled with the BOM. A picture showing five accessories is a product claim; if the production kit contains four, the image is misleading even when the text is correct.

Receiving Inspection for Distributors

Receiving teams can use a risk-based inspection rather than opening every carton.

Confirm outer label and purchase-order revision.
Sample kit weight to detect gross missing-component errors.
Open the defined sample quantity and reconcile every BOM line.
Inspect corrosion, seal condition, encoder protection, threads, and connector damage.
Scan barcodes and verify part, lot, and quantity data.
Retain photographs or samples for the first shipment and after approved changes.
Quarantine any shipment where contents differ from artwork, specification, or sample approval.

Do not substitute a weight check for BOM verification. Two incorrect bolts can weigh approximately the same as two correct bolts.

Common Kit-Content Failures

“Hardware included” without a list

This wording prevents reliable quotation comparison. Require component names and quantities.

Mixing optional and mandatory items

If markets or applications require different hardware, create controlled kit variants or qualifier rules.

Reusing an old product image

Update images when the BOM changes. Archive the previous revision to support traceability.

Supplying a generic axle nut

Thread, locking method, coating, and torque condition must match the application.

Loose hardware damaging the bearing

Separate metal accessories from seals, encoders, connectors, and finished flange surfaces.

Uncontrolled supplier substitutions

Changing a bolt, seal, ring, grease, or sensor can affect function. Apply supplier change control to all kit lines, not only the bearing.

Questions to Put on the RFQ

What is the exact kit number and core bearing or hub number?
Which application and OE references support the kit?
What is the full BOM with quantities and drawing revisions?
Which items are installed and which are supplied loose?
Are any fasteners specified as single-use by the approved service source?
Does the kit include an encoder, sensor, cable, connector, or clips?
How are seals, encoders, threads, studs, and loose hardware protected?
What pack-out inspection prevents missing or wrong components?
How are BOM, artwork, barcode, and catalog changes approved?
Can the supplier provide sample and shipment traceability for every kit line?

Frequently Asked Questions

Does every wheel bearing kit include an axle nut?

No. Inclusion depends on the service procedure and commercial kit definition. Confirm the controlled BOM.

Are mounting bolts always reusable?

No universal rule applies. Follow the vehicle manufacturer’s approved service information for the exact application. If the kit supplies new bolts, verify their specification.

Is a hub assembly itself a kit?

Not necessarily. A hub assembly is an integrated component. A kit is a commercial package that may contain the assembly plus defined accessories.

Can a supplier change kit hardware without approval?

That depends on the quality agreement, but safety-conscious buyers should require notification and approval for functional substitutions.

Should kit contents appear in PIES data?

The Auto Care Association describes PIES as the standard for communicating product information, and official educational material lists kit content among product information elements. Implement the current licensed standard and customer requirements rather than inventing a private field structure.

Procurement Conclusion

A wheel hub bearing kit should be purchased as a controlled system. The core bearing may be correct while the commercial kit is still wrong because a nut, ring, seal, bolt, sensor accessory, label, or packaging control is missing. The solution is a line-by-line BOM connected to drawings, fitment evidence, sample approval, artwork, inspection, and change control.

When requesting a quotation, provide the OE references, vehicle and axle qualifiers, desired kit level, target market, packaging requirements, annual volume, and any customer-specific data standard. Use the JNHJDP contact page to submit the controlled inquiry rather than relying on a generic phrase such as “complete wheel bearing kit.”
